European size stacking containers XL with ribbed base RX
with hinged two-part lid
Short Description
-
large volume
-
transport and storage of sensitive products in manually serviced environments as well as in automated warehouses
-
designed for storing heavy items
-
reinforced corners and sturdy base ribbing provide added strength and high rigidity – ideal for use in automated storage facilities
-
BITO's most versatile container series suits almost any storage, manufacturing and transport/distribution application
£95.00 / each
Ex. VAT, Free UK mainland delivery - detailsOrder products as a set
European size stacking containers XL with ribbed base RX
Product Details
Euro Stacking Container XL – with ribbed base and hinged two-piece folding lid
This XL Euro stacking container has a ribbed base for stability and a two-piece folding lid for security.
This Euro stacking container is ideal for use on conveyor belt systems and automated warehouses, thanks to its RX ribbed bottom.
The ribbed floor of this container is specially reinforced to provide maximum stability when placed on conveyor belts. The ribs are diagonal, so the box creates less noise when being handled on conveyors. You can order this container in different sizes and heights, ensuring you'll find the perfect fit for every requirement. These boxes also have ergonomic handles with a through-grip design, so they can be handled easily manually.
Other accessories can be ordered, including soft-touch handles and drainage holes to keep contents as dry as possible in wet environments. The hinged two-part lid protects your contents from contamination and intrusion of dust and moisture. What's more, the lightweight plastic will withstand temperature changes within a range of -20 to +80°C.
Technical specifications
| Bin type | XLD86321RX |
|---|---|
| Internal dimensions at the top L x W | 762 x 562 (mm) |
| External dimensions L x W | 800 x 600 (mm) |
| Height | 338 mm |
| Inside height | 295 mm |
| colour | blue |
| Material | PP |
| Volume | 118 litres |
| Stacking load | 800 kg |
| Load capacity AKL | 50 kg |
| Load capacity | 50 kg |
| Temperature range | -20°C to +80°C |
| Base option | Ribbed base RX with diagonal ribbing on running surface |
| EAN | 4250692968614 |
Features
Standard base
The standard base will be your choice for loads of up to 30 kg.
Ribbed base
Ribbed base containers are perfect for loads of up to 50 kg. Base deflection is very low.
Ribbed base RX
Containers with a ribbed RX base carry up to 50 kg. Base deflection is very low. Diagonal outer base ribbing ensures excellent use on conveyors.
Double base
Double base containers take loads of up to 50 kg and only have a minimum base deflection.
Snap lock lid
Suited for stacking containers XLD21121, ideal for shipping spare parts etc. Additional security tagging with KLTP tags possible.
Drop-on lid AD
Closes an individual container or a container stack and is suited for automated lidding and strap-sealing.
Drop-on lid ASDV
One-piece lid, hinged on one side and closed with 2 snap-on fixtures on the other side.
Hinged lid
Two-part lid suited for strap-sealing and security-tagging with KLTP security seals, excellent for distribution and transportation applications.
Downloads
Technical data sheet
Declaration of conformity
Brochure
