Cladded shelving - shelf load 100 kg
with solid cladding on the rear and on the sides, galvanised finish
Short Description
-
boltless galvanised steel shelving with cladding on the sides and back
-
choose solid or mesh cladding
-
cladding ensures items do not fall off shelves
-
mesh cladding retains an open and airy aspect to shelving
-
cladded side frames are delivered pre-assembled
-
40mm high shelves are adjustable in 25mm increments
-
starter and extension bay design to enable a run of shelving to be built
-
shelf dividers can be positoned at 50mm intervals
-
100kg shelf load, 1300kg bay load
-
5 shelves
-
Shelving units must be adequately secured against tipping:
• if the height of the top shelf in relation to the shelving depth is greater than 5:1
• if shelving units are equipped with hinged doors with a height-to-depth ratio greater than 4:1
• if shelving units are fitted with pull-out levels (e.g. drawers) or with ladders
Product Details
Technical specifications
| Description | with solid cladding on the rear and on the sides, galvanised finish |
|---|---|
| Height | 2000 mm |
| Shelf width | 1300 mm |
| Shelving height | 2000 mm |
| Length | 1358 mm |
| External bay width | 1358 mm |
| External bay depth | 424 mm |
| Useable depth | 400 mm |
| Description | Starter bay |
| Depth | 424 mm |
| Shelf load | 100 kg |
| Bay load | 1300 kg |
| Number of shelves | 5 |
| colour | galvanised |
Features
Uprights
High load capacities are achieved through precision steel bending to ensure sufficient rigidity for realising shelving heights of up to 10 metres.
Slim 50 mm profiles contribute to maximum space utilisation.
Frames
Easy boltless assembly on site for perfect adaptation to your location.
Level spacing can be adjusted in 25 mm increments to suit your needs.
Beams
Beams and uprights form a solid force-fit connection that provides excellent lateral stability. The three location hooks of each beam connector conveniently slot into the upright perforations.
Safety pins prevent that the beam is accidentally dislodged.
Shelves
Sturdy shelves with shelf clips Our shelves feature box-profiled edges at the long sides and triple edge bending at the short sides.
Reinforcing longitudinal ribs and pressure-bonded corners ensure excellent stability.
All shelves are perforated to accommodate shelf dividers.
