Cladded shelving - shelf load 100 kg
with mesh cladding on the rear and on the sides
zoom
Short Description
-
boltless galvanised steel shelving with cladding on the sides and back
-
choose solid or mesh cladding
-
cladding ensures items do not fall off shelves
-
mesh cladding retains an open and airy aspect to shelving
-
cladded side frames are delivered pre-assembled
-
40mm high shelves are adjustable in 25mm increments
-
starter and extension bay design to enable a run of shelving to be built
-
shelf dividers can be positoned at 50mm intervals
-
100kg shelf load, 1300kg bay load
-
5 shelves
-
Shelving must be adequately secured against tipping by the user:
• if the top shelf height is greater than 5:1 in relation to the shelving depth
• if shelving is equipped with hinged doors with a height-to-depth ratio greater than 4:1
• if shelving is equipped with pull-out levels (e.g. drawers) or ladders
Product Details
Technical specifications
| Description | with mesh cladding on the rear and on the sides |
|---|---|
| Shelf width | 1000 mm |
| Shelving height | 2000 mm |
| External bay width | 1058 mm |
| External bay depth | 324 mm |
| Useable depth | 300 mm |
| Description | Starter bay |
| Depth | 324 mm |
| Shelf load | 100 kg |
| Bay load | 800 kg |
| Number of shelves | 5 |
| colour | galvanised |
Features
Uprights
High load capacities are achieved through precision steel bending to ensure sufficient rigidity for realising shelving heights of up to 10 metres.
Slim 50 mm profiles contribute to maximum space utilisation.
Frames
Easy boltless assembly on site for perfect adaptation to your location.
Level spacing can be adjusted in 25 mm increments to suit your needs.
