Folding boxes EQ
with ribbed base and with hinged two-part lid
zoom
zoom
Short Description
-
space saving ratio of 1:4 when storing and transporting empty bins
-
EQ folding boxes feature a unique, simple and ergonomic folding mechanism
-
also suited for use in automated storage & retrieval systems
-
designed for storing heavy items
-
The lid protects contents from dirt and damage. Optionally available security seals deter tampering and theft.
Product Details
Space saving collapsible EQ containers with ribbed RX base and a hinged folding lid
Your compact, practical and versatile choice
If you are looking for an efficient alternative to your current storage boxes, these EQ containers from the BITO range are a must. Developed in collaboration with ergonomists, these boxes are suitable for all industries and are extremely easy to handle.
When folded, these boxes are only 25% of their size, making them ideal for anyone who has trouble finding space for new products in their warehouse. They are also useful for anyone who simply wants to save space, especially on the return trip from the customer to the distribution centre when all the boxes are empty.
The robust design and ribbed base make the EQ folding box suitable for many areas of application, even for automated warehouses. The space-saving containers are available in different colors for easy identification. Customers can choose between boxes with open handles and fold-up handles. If the contents of the boxes need special protection, the containers are available with a sealable hinged lid.
Made of high-quality plastic, these boxes come with a 5-year BITO warranty. EQ boxes with a ribbed base can carry up to 50 kg and can boast a stacking load capacity of up to 180 kg. They are temperature resistant from -20 to +90°C which increases durability and ensures a long service life, even under adverse conditions.
Dimensions
| External dimensions L x W | 600 x 400 (mm) |
|---|---|
| Height | 332 mm |
| Inside height | 295 mm |
| Inside length base | 566 mm |
| Inside length top | 568 mm |
| Inside width base | 366 mm |
| Inside width top | 368 mm |
| Length | 600 mm |
| Width | 400 mm |
Technical specifications
| Base option | Ribbed base |
|---|---|
| Bin type | EQD64321R |
| colour | blue/grey |
| Customization | Nein |
| Handle | grip opening |
| Lid | with hinged two-part lid |
| Load capacity | 50 kg |
| Material | polypropylene |
| sku | 51-31481 |
| Stacking load | 180 kg |
| Volume | 61 litres |
Features
Sides lock open with a simple push of the thumb or the heel of the hand on the box shoulder. Developed in cooperation with leading
ergonomicists.
Fold-up handles
Fold-up handles are an ideal alternative to open handles to prevent unauthorized access to the contents and allow full use of the bin volume as well as easy handling.
Hinged interlocking lids (optional)
permanently attached to the box, can be secured with tamper-evident seals
Optional label pocket on the short side
The shipment details are inserted into the window from the inside of the box (preventing the loss of the label during transit), but can still be read from the outside. Available to order.
Downloads
Technical data sheet
Declaration of conformity
Product Safety and Security Information Bins and Containers (GPSR)
Brochure
